Oppo R9 R9KM Firmware

Categories : Oppo

Unlock First, When flash failed Click Here

How to Flash Oppo R9 R9KM Firmware via SP Flash Tool (Scatter File)? With this flash file stock rom, android that has problems like bootloop or forgot password will be easy to overcome. If it happens to your Oppo, you can try this Oppo R9 flash mode to solve it. The need to remember is after flashing Oppo is done, the data stored in the internal memory will be erased. So always backup the data first before execution flash file. Because this way will replace the damaged system files or errors become fresh or normal again.

Oppo R9KM Flash File via SP Flash Tool

With this Tutorial How to Flash Firmware Oppo R9 R9KM via SP Flash Tool, you can also solve other error problems, such as:

  • Forgot Password
  • Oppo R9 Stuck on Logo
  • Forget Pattern
  • Bootloop
  • Soft Brick
  • Blank Screen
  • The touch screen is not sensitive
  • Slow not responsive / Hang
  • Virus malware
  • Unfortunately, the app has stopped
  • Oppo often restarts itself
  • And other errors

Read Also:  How to Flash Oppo Neo 5 R1201 Flash File via SP Flash Tool

Tools and Firmware Download

  1. MTK USB Driver
  2. USB Driver VCOM (install when flash won’t running)
  3. CDC Driver Installer (Optional, install when the device can’t detect on PC)
  4. SP Flash Tool V5 (Use SP Flash Tool V3, if the scatter file does not load)
  5. USB Cable Data
  6. Download firmware Oppo_R9KM_MT6755_EX_11_A.33_160918.zip stock ROM via Google Drive
  7. If you get Limit Google Drive, you need to login to your Gmail account or follow this tutorial Bypass Google Drive Download Limit (Quota Exceeded) Error

Read Also:  Flash Oppo F1S A1601 Firmware

How to Flash Oppo R9 R9KM Firmware via SP Flash Tool

  1. First of all, get all the tools and extract the .zip file.
  2. Extract the Oppo R9 flash file and you will see “MTxxxx_Android_scatter.txt“.
  3. Install USB driver.
  4. Install and run the SP Flash Tool application.
  5. Click on Scatter-loading, then open the folder of Oppo firmware, then click “MTxxxx_Android_scatter.txt“.Scatter Oppo R9 R9KM Firmware
  6. Wait until the firmware is loaded.
  7. Uncheck on the Preloader file when you are not sure of this ROM for Oppo R9 R9KM. This will prevent hard brick, this is optional.Remove Preloader SP Flash Tool
  8. Make sure to select Download Only mode, then click the Download button.Start Flashing Oppo R9 R9KM
  9. Now Turn off your device and remove the battery (for non-removable battery, just need to turn off the device).
  10. Press Volume Up and connect the device to PC (press Volume Down when flash not running, unplug the cable before reconnect, and repeat the steps above).
  11. Flash will run automatically.
  12. Wait until flashing finishes with a green sign.Flash Succcessful
  13. Unplug the cable and turn on your device.
  14. The first booting process will take 10-15 minutes, so just wait until entering the wizard menu.
  15. Flash Oppo R9 R9KM firmware is done.

Read Also: Download Oppo N3 N5206 Flash File


  • When the device can’t detect on PC, try to reinstall the driver (optional drivers).
  • When flashing won’t running on “Download Only” mode, change with “Firmware Upgrade” mode, disconnect the device before reflashing.
  • When getting bootloop after flash, try to hard reset via recovery.

Firmware Upgrade Oppo R9 R9KM
